TECHNICAL LIBRARY
Evolution Doors
TECHNICAL DRAWINGS
PROFILE CHARTS
SIZE LIMITS
COLOURS
DOOR STYLES
CLEAR OPENING WIDTHS
Formula to calculate the clear opening width & throw when door is open at 90°
SINGLE DOOR
CLEAR OPENING
Width - 163
THROW
Width - 54
DOUBLE DOOR
CLEAR OPENING
Width - 182
THROW - MAIN DOOR
(Width ÷ 2) - 13
THROW - SLAVE DOOR
(Width ÷ 2) + 23
HARDWARE
STANDARD LEVER/LEVER
DOOR HANDLES
STANDARD LEVER/PAD
DOOR HANDLES
STANDARD LETTERPLATES
REGENCY HANDLES
REGENCY HARDWARE
WROUGHT IRON
DOOR HANDLES
WROUGHT IRON
HARDWARE
MAINTENANCE
